Amphibious vessel Β·Ingalls Shipbuilding

LHA-1 Tarawa-class

American amphibious assault ship, introduced in 1976, displaces 39,967 tons. Key figures: displacement 39,967 tons, length 254 m, top speed 24 knots, crew 930, built 5. In service with 1 navy β€” United States.

Displacement
39,967tons
Max speed
24knots
Ships built
5
Technical Specifications
SubtypeAmphibious assault ship
Displacement39967 tons
Crew930 members
Width40.2 m (131.9 ft)
Length254.0 m (833.3 ft)
Propulsion

2 Γ— Combustion Engineering boilers, 2 Γ— Westinghouse turbines, 70,000 horsepower (52,000 kW), 2 Γ— propeller shafts, 1 Γ— bow thruster

Shaft power70,000 hp
UnitsUSS Tarawa, USS Saipan, USS Belleau Wood, USS Nassau, USS Peleliu
Performance
Range 10,000 nm at 20 knots
Maximum speed24 knots
Armament
Armament
  • Mark 49 RAM missile system
  • 2 Γ— Vulcan Phalanx
  • 6 Γ— 25 mm automatic cannons
  • 8 Γ— 12.7 mm machine guns
  • 2 Γ— 8 cell MK-25 NATO Sea Sparrow BPDMS launchers
  • 3 Γ— 5-inch (127 mm) Mk 45 lightweight guns
Air Park
  • 19 Sea Stallions
  • 26 Sea Knights
  • 6 Harrier jump-jets
Operators
πŸ‡ΊπŸ‡Έ United States
Similar Ships
LHA-1 Tarawa-class vs

Description

The Tarawa class of Landing Helicopter Assault (LHA) ships was developed for the United States Navy to succeed the Iwo Jima class. Built by Ingalls Shipbuilding in Pascagoula, Mississippi, the program was initiated during fiscal year 1969. Although nine vessels were originally contracted, the order was reduced to five ships in 1971. Design challenges early in the program led to increased Navy involvement in the development process, deviating from the original procurement concept. The remaining four planned hulls were canceled, with the Wasp class later succeeding the design.

The class was designed to transport and deploy a reinforced battalion of the United States Marine Corps. The vessels utilize a flight deck with aircraft lifts to operate a variety of rotorcraft, including Sea Stallions and Sea Knights. Following modifications, the class also operated Harrier jump-jets. For amphibious operations, the ships feature a stern well deck capable of embarking and launching various landing craft, such as LCU and LCM designs, and amphibious vehicles. Internal space is allocated for marine personnel, vehicles, and equipment stores. Propulsion is provided by boilers and turbines driving two propeller shafts, supplemented by a bow thruster. The defensive suite evolved over the service life of the class; original guns and Sea Sparrow systems were removed or replaced by RAM missiles, Phalanx close-in weapon systems, automatic cannons, and machine guns. Countermeasures include towed torpedo decoys and chaff launchers.

The lead ship, USS Tarawa, entered service in 1976, followed by four additional vessels through 1980. The class remained in active service until the early 21st century. Decommissioning of the vessels began in 2005 with USS Belleau Wood. USS Peleliu, the final active ship of the class, was decommissioned in 2015. Following their removal from active service, two ships were scrapped and three were expended as targets: Belleau Wood in 2006, Tarawa in 2024, and Peleliu on 17 July 2026 during a RIMPAC sinking exercise north of Kauai, where an unmanned surface vessel delivered a strike in a service first. Peleliu had been the last hull held in reserve, and no units of the class remain. The class was replaced by the America-class amphibious assault ships.

Wikipedia (CC BY-SA) and other open sources. Last updated on 8 August 2026. Suggest a change

Frequently Asked Questions

What type of ship is the LHA-1 Tarawa-class?
The LHA-1 Tarawa-class is a amphibious vessel (Amphibious assault ship) built by United States.
What is the displacement of the LHA-1 Tarawa-class?
The LHA-1 Tarawa-class has a displacement of 39,967 tons.
What is the maximum speed of the LHA-1 Tarawa-class?
The LHA-1 Tarawa-class has a maximum speed of 24 knots (44 km/h).
What is the range of the LHA-1 Tarawa-class?
The LHA-1 Tarawa-class has a range of 10,000 nautical miles (18,520 km) at 20 knots.
How many crew members serve on the LHA-1 Tarawa-class?
The LHA-1 Tarawa-class has a crew complement of 930 personnel.
How many LHA-1 Tarawa-class ships have been built?
5 vessels of the LHA-1 Tarawa-class have been built.
Which countries operate the LHA-1 Tarawa-class?
The LHA-1 Tarawa-class is operated by United States.
