Patria 6×6

Introduced in 2021, the Finnish Patria 6×6 is an armored personnel carrier featuring continuous six-wheel drive and independent suspension for modular troop transport.

Max speed
100km/h
Range
700km
Produced
300units
Patria 6×6 armored personnel carrier side profile drawing
Side profile · Patria 6×6 · length 7.5 m
Technical Specifications
Sub-typeArmoured personnel carrier
Crew2-3 (commander, driver, optional gunner) plus 8-10 troops personnels
Range700 km
Mass22.0 tons
Height2.5 m (8.2 ft)
Width2.9 m (9.5 ft)
Length7.5 m (24.6 ft)
Max. speed100 km/h (62 mph)
EngineScania DC09 in-line 5 diesel, 294 kW (394 hp)
Weapon 1Machine gun
Weapon 225/30 mm medium calibre direct fire weapon system
Weapon 3Patria Nemo 120 mm turreted mortar system
Historical Operators
🇩🇪 Germany· 🇩🇰 Denmark· 🇫🇮 Finland· 🇱🇻 Latvia· 🇸🇪 Sweden· 🇺🇦 Ukraine
Compare This Vehicle
Patria 6×6 vs

Description

The Patria 6×6, also designated XA-300, is an armored personnel carrier developed by Finnish defense manufacturer Patria. Built using chassis structures and components from the Patria AMVXP, the vehicle was designed primarily for troop transport with an expected service life exceeding 30 years. Patria launched the platform at the Eurosatory exhibition in June 2018, later exhibiting a 120 mm Patria Nemo turreted mortar variant at DSEi 2019 and a Heavy Armoured Personnel Carrier variant equipped with a 25 mm remote weapon system at DSEi 2021. In early 2020, Finland, Estonia, and Latvia established the Common Armoured Vehicle System (CAVS) joint development programme centered on the platform, though Estonia later withdrew. Sweden and Germany joined the CAVS programme in 2022, followed by Norway and the United Kingdom in September 2025.

The internal layout places the driver and commander at the front, the engine compartment behind the driver, and the troop compartment at the rear. A passage on the right side allows movement between the front and rear sections. The platform supports modular tailoring and optional additions, including a swimming system, recovery winch, upgraded armor protection, and various weapon mountings. Armament choices extend from light or heavy machine guns to 25/30 mm medium-caliber direct-fire cannons and the Patria Nemo 120 mm turreted mortar. Production configurations encompass armored personnel transport, command and control, medical transport, armored reconnaissance, engineer group transport, and fire control variants.

The Patria 6×6 is deployed by several European armed forces. Finland received pre-series vehicles for military evaluation in 2022 prior to issuing serial procurement contracts. Latvia took initial deliveries in October 2021 and established domestic assembly at a manufacturing facility in Valmiera. Sweden adopted the vehicle under the service designation Pansarterrängbil 300, while Germany selected the platform as the TPz NG to succeed its TPz Fuchs fleet. Danish Army variants utilize an M18 ring turret fitted with an M2 Browning machine gun and four smoke-grenade dischargers per side. Ukraine also operates the vehicle through procurement contracts and foreign transfers funded by Latvia.

Frequently Asked Questions

What type of vehicle is the Patria 6×6?
The Patria 6×6 is a Finland armoured personnel carrier classified as a armored personnel carrier.
What is the weight of the Patria 6×6?
The Patria 6×6 has a combat weight of 22.0 tons (22,000 kg).
What is the maximum speed of the Patria 6×6?
The Patria 6×6 has a maximum road speed of 100 km/h (62 mph).
What is the operational range of the Patria 6×6?
The Patria 6×6 has an operational range of 700 km (434 miles) on roads.
How many crew members does the Patria 6×6 require?
The Patria 6×6 requires a crew of 2-3 (commander, driver, optional gunner) plus 8-10 troops personnel to operate.
How many Patria 6×6 have been built?
Approximately 300 units of the Patria 6×6 have been produced.
What weapons does the Patria 6×6 carry?
The Patria 6×6 is armed with Machine gun, 25/30 mm medium calibre direct fire weapon system and Patria Nemo 120 mm turreted mortar system.
