Gulfstream IV
American business jet from the late 20th century, recognized for its widespread use in corporate and private aviation. Key figures: top speed 935 km/h, range 7,815 km, service ceiling 13,716 m, max takeoff weight 33,520 kg, unit price $26M, built 900. In service with 7 air forces as of 2026 โ Japan (5), Algeria (4), Chile (4) and 4 others.

| Crew | 2 |
| Length | 27.2 m (89.4 ft) |
| Wingspan | 23.5 m (77.1 ft) |
| Height | 7.7 m (25.2 ft) |
| Wing area | 88.3 mยฒ (950.5 sqft) |
| Empty weight | 19,504 kg (42,999 lbs) |
| Max. takeoff weight | 33,520 kg (73,899 lbs) |
| Powerplant | 2 ร turbofans Rolls-Royce Tay 611-8C 6,282 kgf each |
| Maximum speed | 935 km/h (581 mph) |
| Operational range | 7,815 km (4,856 mi) |
| Service ceiling | 13,716 m (45,000 ft) |
Description
The Gulfstream IV (G-1159C) is a family of twin-engine business jets built by Gulfstream Aerospace, a General Dynamics company, at Savannah, Georgia, between 1985 and 2018. Developed as a re-engined and stretched derivative of the Gulfstream III, it is powered by two Rolls-Royce Tay turbofans and was the first business jet with an all-glass cockpit. The family includes the GIV, GIV-SP, G300, G400, G350 and G450, with more than 900 built in total. In military service it is flown as the C-20F, C-20G, C-20H and C-20J in the United States and as the S 102B Korpen in Sweden, among other operators.
Development
Work began in March 1983, with Grumman, on a re-engined, stretched derivative of the Gulfstream III. The first aircraft flew on 19 September 1985, FAA certification followed on 22 April 1987, and the type entered service that year, starting at serial 1000. In June 1987 a Gulfstream IV set 22 class records flying west around the world in 45 hours 25 minutes. The upgraded GIV-SP was introduced from serial 1214 in 1993 and redesignated G400 from serial 1500; a shorter-range G300 followed in 2002.
The GIV-X, begun in 2001, became the G450: it first flew on 30 April 2003, received FAA approval on 12 August 2004 and entered production in October 2004, replacing the G400. The G350, a reduced-fuel version, was certified in 2004. The last G450 was delivered on 19 January 2018 after 365 G450s over 12 years, ending a 30-year production run; more than 900 GIV, GIV-SP and G450 aircraft were built. The G450 was replaced by the G500. The Gulfstream V, a development of the GIV, followed in the 1990s.
Design
The wing structure was redesigned for lower weight. Aerodynamic changes were confined to the forward 65% of chord, so the control surfaces were unchanged, and the inboard wing was left alone. The outboard changes weaken and sweep the shock, giving lower cruise drag, a lower root bending moment, a lower stall speed and more fuel volume; range grew by 560 km (300 nmi) over the Gulfstream III. The Tay engines, rated at 55.2 kN (12,420 lbf) against the 51 kN Speys of the GIII, brought gains in speed, noise, emissions, fuel economy, range and payload. The GIV was the first business jet with an all-glass cockpit, the Honeywell SPZ-8000; the SPZ-8400 later became standard.
The G400 has a range of 8,060 km (4,350 nmi) and a maximum cruise of Mach 0.85 at 13,700 m (45,000 ft). The G450 has a fuselage 30 cm (12 in) longer with the main door moved aft, the forward fuselage and larger cockpit of the G550, Tay 611-8C engines with FADEC, redesigned reversers, nacelles and pylons, and the PlaneView cockpit with four 36 cm (14 in) displays and a head-up display.
Military and government service
In the US armed forces the family carries the C-20F to C-20J designations. The C-20F is a US Army GIV executive transport, one of which remained in service as of January 2025. The C-20G serves the Navy and Marine Corps and can carry cargo, up to 26 passengers, or a mix (three pallets; two pallets and eight passengers; or one pallet and 14 passengers), using a starboard hydraulic cargo door and a roller floor; it was flown by VR-48 at Andrews until that squadron's deactivation in 2012 and by the Marine Corps detachment at Kaneohe Bay, Hawaii. The C-20H is a USAF GIV-SP executive transport and the C-20J a US Army GIV-SP.
The Swedish Air Force operates two S 102B Korpen electronic intelligence aircraft. Other operators include the Japan Air Self-Defense Force (five), the Chilean Air Force (four), the Pakistan Air Force (two GIV-SP) and Pakistan Army Aviation, the Royal Saudi Air Force (two), the Royal Netherlands Air Force, Ivory Coast, Tanzania, and the Brunei and Johor state flights. Former operators include the Irish Air Corps, which used the type for government transport, and Uganda, which bought a GIV-SP in December 2000 for presidential flights and replaced it with a G550 in February 2009.
NOAA flies a GIV-SP at 13,700 m (45,000 ft) around tropical cyclones, releasing dropsondes along a track of about 6,400 km to measure wind, pressure, humidity and temperature for National Hurricane Center forecasts; a tail Doppler radar was added in 2009.
Variants
- GIV: initial production version, from serial 1000 in 1987.
- GIV-SP: upgraded version from serial 1214, 1993.
- G400: GIV-SP redesignated from serial 1500.
- G300: shorter-range version, 2002.
- G450: developed from the GIV-X; longer fuselage, G550 forward fuselage and cockpit, Tay 611-8C engines, PlaneView cockpit; in production from October 2004 to 2018.
- G350: reduced-fuel version of the G450, certified 2004.
- C-20F: US Army GIV executive transport.
- C-20G: US Navy and Marine Corps cargo and passenger version with cargo door and roller floor.
- C-20H: USAF GIV-SP executive transport.
- C-20J: US Army GIV-SP.
- S 102B Korpen: Swedish Air Force electronic intelligence aircraft.
